Stainless ball coupling, inner female thread

61 .70 € - 82 .25 €

CB2070003150

Stainless ball coupling, inner female thread

Share in WhatsApp

61 .70 € - 82 .25 € 61 .70 €

Tax included

Stock

Tecniman CB207 stainless-steel ball half with a female thread and C-03 coupling. Options: 1½″ (40) and 2″ (50); select by the equipment's male thread, not the hose. Requires a compatible C-03 latch and seal; stainless grade, thread standard, pressure and food-contact status are not stated.

Size

1 1/2"
2"

61 .70 € - 82 .25 € 61 .70 €

Tax included

Stock

Options

CERRAR

Quantity

Select options Options

Express Shipping

Return Guarantee

Safe payment

Details of Stainless ball coupling, inner female thread

CB207

SERIES

C-03

COUPLING

1½″ / 2″

FEMALE THREAD

INOX

GRADE N/S

Tecniman CB207 stainless-steel ball half with an internal female thread, forming the ball end of a C-03 coupling.

Female is the thread that receives the equipment's male port. The ball engages a C-03 lever-latch half; both options share that coupling size.

01 · MALE OR FEMALE

The equipment decides the gender, and it works the opposite way round

This is the costliest mistake with this part, and it is made every day: you do not choose the ball end by what you are holding, but by the thread of the port it is going onto. Look at the outlet on the pump, the tank or the filter, and decide afterwards. If the port on the equipment has a male thread, the part that goes on is this one, the female; if the port is female, what you need is the male-threaded ball end.

The port on the equipment is male	This ball end, with an internal female thread (CB207).
The port on the equipment is female	The ball end with an external male thread (CB206), not this one.

02 · CHOOSE THE OPTION

Match the equipment thread, not the hose

Choose 1½″ —40 mm, reference CB2070003150— or 2″ —50 mm, CB2070003200— to match the male thread on the pump, vessel or fitting. Tecniman states only the nominal inch size, not the standard, pitch or measured diameter. Verify the equipment thread or its data sheet; never force a near match or choose by hose diameter.

03 · INSTALL AND CHECK

Complete the assembly with a compatible C-03 latch and seal

Stop, drain and depressurise the line; inspect the thread, ball and sealing edge. Fit the part to a compatible port using a sealing method suitable for the fluid. Engage only with a C-03 lever-latch half and a clean, intact, compatible C-03 O-ring. Run a controlled leak test; never couple under pressure or use this fitting as an isolating valve.

04 · BEFORE YOU BUY

Stainless steel alone is not food-contact certification

Tecniman states agricultural, industrial, public-works, water-transfer and general uses. It does not document stainless grade, elastomer, pressure, temperature or food-contact compliance. For honey contact, verify every wetted material and the cleaning procedure. Reject pitted, distorted or sealing-surface-damaged parts. Latch half, hose and O-ring are not stated as included.

SUITABLE	A compatible male port and C-03 lever-latch half.
CONFIRM	Actual thread, seal, pressure, temperature and circuit suitability.
DO NOT ASSUME	304/316 grade, food approval or included accessories.

CONFIRMED DATA AND LIMITS

Manufacturer / supplier	Técnica y Mantenimiento, S.A. · Tecniman
Family	CB207 · female-threaded ball half
LTA options	1½″ (40 mm nominal) · 2″ (50 mm nominal)
References	CB2070003150 · CB2070003200
Stated material	Stainless steel; grade not specified
Equipment connection	Internal female thread; standard and pitch not stated
Coupling interface	Ball end · C-03 coupling for both options
Mating half	C-03 lever-latch coupling; LTA 1174 for 40/50 mm hose
Seal	C-03 O-ring; listed separately by Tecniman as DA398
Supplier applications	Agriculture · industry · public works · water transfer · general use
Not documented	Pressure · temperature · elastomer · food-contact compliance
Equivalent part in male	CB206 · LTA 1177, for equipment with a female port
Function	Coupling component; it does not regulate or isolate flow
