508 × 424 mm BOX OUTSIDE | 22 mm SOLID PINE |
3 ADJUSTABLE ENTRANCES | 20 kg EMPTY, COMPLETE |
Langstroth brood box for apiaries that travel: body and floor in a single block of 22 mm solid pine, with stacking rails, a metal roof with catches and the 10 wired Hoffman frames inside.
It is the brood-box-only version: the box you need to start a colony or replace fleet equipment without paying for supers you will not use yet.
01 · WHY MIGRATORY
Look at the outside: the battens standing proud top and bottom are the perimeter rails, and the floor is joined directly to the body, with no ironmongery and no moving parts. On the road that means less vibration on the brood and nothing that opens up in a pothole. The top rail takes the super or the roof by location, and since there is no landing board sticking out, the hive sits flat on the truck bed and loads with a sack truck or forks without catching. The roof stays married to the body with quick-release metal catches you can flick open one-handed on arrival.
02 · VENTILATION
It carries three adjustable metal entrances: two in the floor and a third higher up in the body. As well as matching the entrance to the strength of the colony through the season, they have a closed position with a ventilation mesh: you shut the way out for a night move and the air keeps moving. That is what stops a strong colony suffocating shut in on a summer night, which is the real risk of moving hives. The upper entrance adds draw with the hive closed, and the galvanised roof has side vents of its own.
03 · BUILD
The four corners are assembled with interlocking fingers: the mechanical joint carries the load and the nails only close it, which is what holds up when the whole thing travels loaded. The finish is one coat of linseed oil, not paint or varnish — it protects against damp without sealing the pores, lets the timber breathe, and after a few years is renewed with another coat, no stripping. Inside nothing is painted or oiled: the bees see to that with propolis.
04 · WHICH FLOOR?
Because the floor is joined to the body, this is the one choice with no way back. The solid floor is the classic closed wooden bottom: more shelter in winter and fewer parts to clean. The open mesh floor is a screen with a removable tray: it ventilates in hot country and lets you read the natural varroa drop without opening the hive — an indicative count to be read alongside the season, the strength of the colony and the treatment applied, and one that does not replace treatment.
05 · BEFORE YOU BUY
It arrives assembled and with the ten frames inside. If you are starting out, what you still need to populate it is foundation — the frames are wired but carry no sheet — and your protective clothing; the super comes later, when the colony has worked almost the whole brood box. The complete unit weighs 20 kg empty: count on help or a trolley if you are placing several.
| ✓ FITS | Langstroth frames of 48 × 23 cm, and Langstroth migratory supers and half supers, by rail location. |
| ✕ DOESN’T FIT | Dadant, Dadant Blatt or Layens, and fixed-site supers with no location rail. |
| ⚠ NOT INCLUDED | Super, foundation or transport straps: the rails steady the stack, but for the road it is secured with a strap. |
| Reference | 010301 |
|---|---|
| System | Ten-frame migratory Langstroth · brood box only, floor joined to the body |
| Contents | Brood box with its floor · metal roof with catches · crown board · 10 wired Hoffman frames · 3 metal entrances |
| Timber and finish | 22 mm solid pine, finger-jointed corners, one coat of linseed oil |
| Box dimensions | Outside 508 × 424 mm · inside 464 × 380 mm |
| Entrances | 3 adjustable metal (2 in the floor, 1 upper), with a closed position and ventilation mesh |
| Floor | Chosen at purchase: solid wooden floor or open mesh floor with tray |
| Weight | 20 kg complete and empty |
