Heater for 200kg honey tanks

Share in WhatsApp

299 .95 €

Tax included

Last items in stock

1000 W silicone heating band for the M09 200 kg stainless-steel honey tank and Ø525 mm vessels. Measures 125 × 1480 mm with a 0–120 °C thermostat, 2 m cable and plug. The dial controls the band, not the honey: use a separate probe and verify the actual diameter before ordering.

299 .95 €

Tax included

Last items in stock

Quantity

Select options Options

Express Shipping

Return Guarantee

Safe payment

Details of Heater for 200kg honey tanks

Ø 525 MM

CONFIRMED FIT

1000 W

RATED POWER

125 × 1480 MM

BAND SIZE

0–120 °C

THERMOSTAT SCALE

A silicone heating band made to fit the 200 kg stainless-steel honey tank with a 525 mm outside diameter. It applies 1000 W over a 125 mm strip to loosen crystallised or highly viscous honey and make transfer easier.

Herten confirmed that the standard size was too large and adapted this version to the Ø525 mm vessel. That diameter—not the nominal “200 kg” capacity—is the decisive fit check. The dial controls the band from 0 to 120 °C; it does not measure the honey, and the top of the scale is not a recommended honey temperature.

01 · FIT AND INSTALLATION

Full contact on a 525 mm metal wall

With the equipment cold and unplugged, offer the band up to a clean, dry metal outer wall. Keep it flat, with no folds or overlap, and close the tension springs without straining the heating body. The 1480 mm version was specified for LTA's M09 200 kg tank with a 525 mm outside diameter; the springs bridge the closing gap, so the silicone ends are not meant to lie over one another. Position it where the wall remains backed by honey, as heating an empty strip of the tank encourages hot spots.

02 · WHAT IS ACTUALLY CONTROLLED

The scale belongs to the band, not the centre of the honey

The built-in thermostat controls the heater, while the honey responds more slowly and can be at a different temperature near the wall and at the centre. Use a separate food-suitable probe in the product, begin at the lowest useful setting and monitor both time and temperature. Mix safely when the process permits to distribute the heat. Research on honey shows that higher temperatures or longer exposure can increase HMF and reduce enzyme activity, so 120 °C is the upper limit of the control scale—not a processing target.

03 · REALISTIC PERFORMANCE

A 125 mm strip cannot heat 200 kg instantly

Heat enters through the contact zone and lowers viscosity for draining or pumping, but the band does not replace agitation or guarantee uniform temperature. Time varies with quantity, crystallisation, starting and room temperatures, vessel, insulation and mixing. No heating time is published. Stop once the necessary flow is achieved; do not hold a high setting by default.

04 · SAFETY AND BUYING CHECKS

Check the vessel, supply and condition before connection

Rated at 230 V and 1000 W, it draws about 4.35 A nominally. The sheet states double electrical insulation and CE marking. Do not use it on plastic, empty, folded, overlapped or damaged. Never immerse any component or seal a vessel hermetically while heating. Keep the process attended, unplug before repositioning and cool before removal. Thermostat, 2 m cable and plug are integral; a honey probe is not listed as supplied.

FITS	LTA M09 stainless-steel tank or metal vessel with an actual 525 mm outside diameter.
CHECK	Outside diameter, flat contact, honey level and 230 V supply.
DO NOT USE	On plastic, empty, overlapped, immersed or with damaged cable or silicone.

CONFIRMED DATA AND OPERATING LIMITS

Product	Silicone heating band for honey tank
LTA reference	BAN200KG
Confirmed fit	M09 200 kg stainless-steel honey tank
Vessel outside diameter	525 mm
Band dimensions	125 mm wide × 1480 mm long
Rated power	1000 W
Supply	230 V
Calculated nominal current	Approx. 4.35 A
Built-in control	0–120 °C thermostat
What it controls	The band; it does not directly measure the honey
Cable	2 m with plug
Construction	Glass-fibre-reinforced silicone with spring closure
Product-sheet declaration	Double electrical insulation and CE marking
Heated area	125 mm contact strip; temperature gradients may occur
Heating time	Not published; depends on product, quantity and conditions
Included	Band, integral thermostat, cable and plug
Not listed as included	Separate probe for measuring the honey
Undocumented use	Outdoor, immersion, plastic vessels or IP rating
