Thermologger HI148-3 Hanna®

Out of stock

Share in WhatsApp

129 .00 €

Tax included

Out of stock

Hanna® HI148-3 logger with an internal sensor and external stainless steel probe on a 1 m cable. Stores 8000 readings per channel at intervals from 2 seconds to 24 hours. Download and analyse data with HI92148 for Windows. Documents honey processing temperature and time; does not measure HMF.

129 .00 €

Tax included

Out of stock

Quantity

Select options Options

Express Shipping

Return Guarantee

Safe payment

Details of Thermologger HI148-3 Hanna®

2 channels

INTERNAL AND EXTERNAL SENSORS

8000

READINGS PER CHANNEL

Keep a temperature and time record to review how each honey batch was heated or stored.

The Hanna® HI148-3 combines an internal sensor for the instrument’s surroundings with an external stainless steel probe on a 1 m cable. You can compare two measurement points, with memory for 8000 readings per channel.

01 · TWO MEASUREMENTS

Place each sensor where it answers your question

The internal sensor measures from −20 to 60 °C and the external probe from −40 to 125 °C. The probe can follow one point in the batch or process while the instrument records its own surroundings. Keep it away from the heated wall when measuring honey temperature. Record its position: a surface reading or a single point does not automatically represent the whole volume.

02 · SETUP

The interval determines how much history you keep

Readings can be logged at intervals from 2 seconds to 24 hours. A short interval captures rapid changes better but fills the memory sooner. As a guide, logging every minute provides a little over five days of monitoring per channel. Set the high and low alarms for your process; they flag deviations but do not disconnect a heater or control the heating system.

03 · TRACEABILITY

Keep the temperature curve with the batch record

HI92148 software for Windows configures the logger and downloads readings by USB. Link each session to the batch, operation and probe position. Keep the table and graph to compare treatment duration and temperature across batches and identify deviations.

04 · BEFORE YOU BUY

Separate resolution, accuracy and certification

Between 0 and 70 °C the stated accuracy is ±0.4 °C; display resolution is 0.1 °C up to 100 °C. Displaying tenths does not mean measurement uncertainty is one tenth. The package includes a USB cable, wall cradle, batteries and quality control certificate. If your quality system requires a traceable calibration certificate, confirm that specific service. Also check software compatibility with the computer you intend to use.

TECHNICAL SPECIFICATIONS

Model	Hanna® HI148-3
Channels and memory	Internal + external · 8000 readings per channel
Internal sensor range	−20 to 60 °C
External probe range	−40 to 125 °C
Logging interval	2 seconds to 24 hours
Accuracy	±0.4 °C from 0 to 70 °C; ±0.5 °C from −40 to 0 °C and from 70 to 100 °C; ±1 °C above 100 °C
Resolution	0.1 °C up to 100 °C; 0.2 °C above
External probe	Stainless steel · 33.5 × Ø3.5 mm · 1 m cable
Connection and software	USB · HI92148 for Windows
Power and protection	3 AAA batteries · IP67
Dimensions and weight	107 × 59 × 17 mm · 130 g
Included	USB cable, wall cradle, batteries and quality control certificate
