190 · 378 mm TWO SIZES · 36 HIGH | 2 POSITIONS |
Galvanised steel plate that covers two jobs with one part: narrowing the entrance for wintering and closing it, ventilated, for transport.
Flip it over to switch function, so it can stay fitted all year round.
01 · THE TWO POSITIONS
In the winter position the lower openings let bees through and narrow the entrance, which also hinders rodents from getting in once the colony has drawn back and no longer defends the whole entrance. Turned over, the row of perforations keeps air moving with the exit closed: that is the position for moving hives. A ventilated closure does not make every journey safe, though — weather, load and duration still rule.
02 · HOW IT FITS
The plate slides into the entrance gap and the 7 mm folded lip rests on the edge of the floor, which is what stops it going in too far. So the first thing is to measure the usable gap: 190 × 36 mm is for a nuc and 378 × 36 mm for a hive, but floors vary between makers and production runs. A little extra width can be filed down and it goes in; if it is short, there is no fix. And plastic floors with a wider entrance — the Nicot type — need the part from that same system.
03 · WHAT IT DOES NOT DO
Worth saying, because it is the most asked question: a bee gets through its openings, so it will not stop a smaller insect — beetles included — nor does it work as an Asian hornet guard. What it reduces is the entrance width and rodent access. It has no fully open summer position either: when the colony is at full strength and needs the whole entrance, take it off. Its ground is wintering and transport.
04 · BEFORE YOU BUY
Measure your floor's gap and choose by that number, not by the hive's name. If you keep nucs and hives in the same apiary, know how many of each: these are two separate references, not one adjustable part.
| ✓ FITS | Wooden floors whose entrance matches 190 × 36 mm (nuc) or 378 × 36 mm (hive). |
| ✕ DOES NOT FIT | Entrances narrower than the plate, and Nicot-type plastic floors with a wider entrance. |
| ⚠ IT IS NOT | A barrier against beetles or Asian hornets, nor an entrance with a summer setting. |
| LTA reference | PLM1904 |
|---|---|
| Material | Galvanised steel sheet |
| Sizes available | Nuc 190 × 36 mm · hive 378 × 36 mm |
| Folded lip | 7 mm |
| Positions | Winter reduction · ventilated transport closure |
| Fitting | Slid into the entrance gap, lip resting on the edge of the floor |
| Compatibility | Entrances matching the chosen size; check the real gap |
