Complete factory filling station: the DANA 2000+ is joined to the Ø 100 cm turntable by a bracket, and the jars come to the filling head on their own.
What you buy here is not the doser: it is the line. You put the empty jars on the table and the rotation carries them one at a time. A sensor detects the jar under the head (both the photo sensor and the wire switch are included), stops the table and starts filling; once the programmed dose is reached, the table turns again. The operator only refills jars and takes away the full ones.
01 · THE TABLE RULES, NOT THE PUMP
The pump gives around 610 kg/h, but that is not the line's rate: the real rate comes from the combination of table speed and jar size. A small jar fills in a second and the table rules; a large one reverses the relationship.
So the figure that matters when sizing is not the pump's but the one from a trial with the format you are going to bottle. Tell us your jar and we will tell you what to expect.
If jars are filled twice or pass through unfilled, check both the speed and T1 BLOCK TIME: this is how long the photo sensor ignores the jar that has just been filled. Readjust it whenever you change jar format or speed, and check jar movement with empty jars before filling.
02 · JARS FROM Ø30 TO Ø115 MM
It takes jars Ø 30 to 115 mm across and 30 to 190 mm tall. That range covers the standard honey line comfortably: half-kilo jars are around Ø 75 × 110 mm and kilo jars Ø 95 × 145.
The rail is set to the jar size, and the filling machine, mounted on the bracket, adjusts vertically and horizontally: that is what lets you change format without changing machine. Declared dosing accuracy is ±1 g, and filling starts at 10 grams.
If you already own a DANA 2000+, note that the Ø 100 turntable sold separately does not come with this bracket: with it, the filling machine stands on a separate floor stand next to the table, either the electric floor stand or the adjustable floor stand. The bracket is not sold separately, so if you already have a 2000+ and want this same set-up, the part you need is the Ø100 turntable with console: this same table, without the filling machine.
03 · THE ANTI-DRIP NOZZLE
Honey strings. Without a clean cut-off at the end of each dose, every jar leaves a thread on the table, on the rim of the next container and on the label. The anti-drip nozzle, with its Ø 20 cut-off cross, is included and it is what separates a presentable line from one you have to clean every hour.
The station also includes a foot pedal, 2" hose, bent fitting, counterflow valve and dosing syringe. The pedal lets you fire a manual dose without taking the jar off the table, useful for topping up or for calibrating.
04 · A 2-INCH CONNECTION: DN50
The hose connection is 2 inch, that is DN50, the size of the large maturers and the room pumps. If your installation is inch-and-a-half (DN40), you will need reducers.
Consumption is 575 W at 230 V — just over two amps — so the electrical side is no problem. The turntable stands on wheels: you roll it to where you bottle and back to its place afterwards. Danish built by Swienty.
05 · BEFORE YOU BUY
A complete bottling line, not a stand-alone doser.
| ✓ A GOOD FIT | Series bottling of jars from Ø 30 to Ø 115 mm, on a DN50 line. |
| ⚠ IT NEEDS FLOOR SPACE | It stands on wheels, so no workbench is needed, but you need room for the station and to refill and remove jars. It ships on a 120 × 80 × 125 cm pallet, 168 kg; measure the space before ordering. |
| ✕ NOT A HAND DOSER | It is a station for series bottling. To bottle occasionally by hand, this is far too much machine. |
| Set | DANA api MATIC 2000+ filling machine joined by a bracket to the automatic Ø 100 cm turntable, on wheels |
|---|---|
| Detection | Photo sensor and wire switch, included |
| Filling range | From 10 g, no upper limit |
| Accuracy | ±1 g |
| Jars accepted | Ø 30 to 115 mm · 30 to 190 mm tall |
| Programs | 20 storable filling programs |
| Pump capacity | About 610 kg/h |
| Adjustment | Rail set to the jar; filling machine adjustable vertically and horizontally on the bracket |
| Connection | 2-inch hose (DN50) |
| Supply | 230 V · 575 W |
| Includes | Photo sensor and wire switch, foot pedal, counterflow valve, 0-60 ml dosing syringe, anti-drip nozzle with Ø 20 cut-off cross, 2" (50 mm) hose with 1½-2" bent BS fitting and hose clamp, 1½" BS nuts, 2 legs and a spare parts set |
| Packaging | Pallet 120 × 80 × 125 cm, 168 kg |
| Built by | Swienty, Denmark |
| Reference | 110885 |
